High Efficiency Communication Module LoRaWAN Node Module WFCM-910LRWN
| Place of Origin: | Changsha, Hunan |
|---|---|
| Brand Name: | Willfar Information Techonology Co., Ltd. |
| Certification: | ICA Standard/ LoRaWAN Specification |
| Model Number: | WFCM-910LRWN |
| Minimum Order Quantity : | 100 |
| Packaging Details : | Carton Packaging |
| Delivery Time : | 30 Days |
| Payment Terms : | T/T |
| Supply Ability : | 2000 per day (based on the number of the order) |
Detail Information
| Communication Distance: | 1~3Km | Opearating Voltage: | 3.0~3.6V |
|---|---|---|---|
| Operating Temperature: | -40~+85℃ | transmission Speed: | 0.018~62.5Kbps |
| transmitting Current: | 1~22dBm（Adjustable ） | ||
| High Light: | 4g module , wireless networking module | ||
Product Description
-WFCM-910LRWN-V1.0 is a LoRaWAN module which integrated the ST low-energy-consumption MCU and SX1268 RF chip, the module conforms to LoRaWAN communication protocol, and support frequency 470~510MHz.
- The module interacts with external devices by providing the serial interface (AT order), which can be customized according to demands. The RX1268 RF chip is smaller in size, more energy-saving and has a longer transmission distance, compared to the previous version RX1278. Customized design and development available for various applications in IOT field, including smart city, AMI, intelligent logistics, wireless sensor communication solution and etc..
Technical Parameters
| Item | Parameter |
| Operating Voltage | 3.0~3.6V |
| Operation Temperature | -40~85℃ |
| Frequency | 470~510MHz |
| transmission Power | 1~22dBm (adjustable) |
| Receiving Sensitivity | SF12/125KHz:-138dBmSF10/125KHz:-134dBmSF7/125KHz:-124dBm |
| Speed of transmitting | 0.018~62.5Kbps |
| Distance of transmission | 1~3Km |
| Modulation Mode | LoRa |
| Operating Current | Sending current:62.15mA Receiving current:26.53mA Standby current:18.8mA Low energy-consuming current:1.8μA |
| Dimension | 23.3x19x0.8mm |
Features
1. WFCM-910LRWN-V1.0 is a LoRaWAN module which integrated the ST low-energy-consumption MCU and SX1268 RF chip.
2. The module conforms to LoRaWAN communication protocol, and support frequency 470~510MHz.
3. The module interacts with external devices by providing the serial interface (AT order), which can be customized according to demands.
4. The RX1268 RF chip is smaller in size, more energy-saving and has a longer transmission distance, compared to the previous version RX1278.
